Heatmiser UH6 6 Zone Wiring Centre

• Up to 4 actuator connection to each zone.
• Central wiring for up to 6 zones.
• Output for underfloor heating valve.
• Pump activated when any thermostat calls for heat.
• Actuator outputs: 230v.
• Dimensions 265 x 95mm.

The Heatmiser UH6 Wiring Centre is a 6 Zone underfloor heating wiring centre designed to work with 230v Thermostats.

The UH6 provides central switching and is therefore ideally situated next to the underfloor heating manifold.

On demand from any zone, a 230v output is provided to switch the relevant zone actuators, underfloor heating pump and valve.

In addition, the UH6 offers pump delay and creepage function, which operates the pump once a day during hot weather to prevent the chance of seizure or malfunction.
